VXDIAG VCX NANO GM: Removing Mag Ride Control on Chevrolet Corvette

Question:

Does the VXDIAG VCX Nano GM scanner have the ability to remove Mag Ride Control from the Chevrolet Corvette's Body Control Module (BCM)?

Answer:
Yes, it does. This can be done in the BCM setup under the "Real Time Damping" section.

User Feedback:

  1. I was able to delete the Real Time Damping and OnStar features using the VXDIAG VCX Nano. It took a lot of effort, but I finally found the correct bin file to use with Tech2Win.
  2. I successfully removed the RTD (Real Time Damping) option from the BCM using VXDIAG Tech2Win.

Example of Mag Ride Control Removal on a C6 Corvette

Steps:

  1. Select "Diagnostic"
  2. Select the model year
  3. Select "Chevrolet"
  4. Select "Product Line"
  5. Select "Vehicle Control Systems"
  6. Select "Computer/Integrating Systems"
  7. Choose manual or automatic transmission
  8. Select "Module Setup"
  9. Select "Body Control Module"
  10. Select "BCM Setup"
  11. Press "Yes" to set up a new BCM
  12. Select "Real Time Damping"

Follow the prompts to complete the BCM setup.
