Description

VXDIAG VCX NANO OBD2 Scanner for GM Chevrolet Cadillac GMC Buick Hummer / OPEL

The VXDIAG VCX NANO OBD2 Scanner is a high-performance diagnostic tool tailored for GM vehicles, including Chevrolet, Cadillac, GMC, Buick, Hummer, and Opel. Supporting vehicle models from 2000 to 2024 (Only GDS2 supports Opel and Saab. Tech2Win does not support Opel and Saab (2000-2010). Does not support Holden.), this scanner serves as a dependable replacement for the GM MDI, offering extensive diagnostic and programming functionalities essential for automotive professionals.

If you need to support Canfd and work on F Series cars, choose VCX FD for GM

Support latest Software version:
GDS2 V2024.05.08
Tech2WIN 16.02.24
DPS2
VX Manager 1.8.9

GM GDS2 Languages: English, German, Spanish, French, Italian, Portuguese, Netherlands, Russian, Arabic, Japanese, Korean, Chinese, Vietnamese
GM Tech2win language: English

Key Features

SAE-J2534 Compatibility: Fully compatible with SAE-J2534-1 and SAE-J2534-2 standards, ensuring broad compatibility across various vehicle systems.
Comprehensive Protocol Support: Supports all current and many legacy vehicle protocols, including CAN, UART, KW2000, Class2, and GM LAN.
Efficient Data Access: Provides quick access to vehicle data for maintenance and management reports, enhancing service efficiency.
Software Compatibility: Compatible with GM Tech-2-Win and GDS2 software, as well as GM SPS2 online programming (requires an online account). Supports the latest software versions, including GDS2 V2024.05.08 and Tech-2-WIN 16.02.24.
Multi-Language Support: Supports multiple languages, including English, Spanish, French, Italian, Portuguese, Dutch, Russian, Arabic, Japanese, Chinese, and Vietnamese.

Connectivity Options

USB and WiFi Connectivity: Offers both USB and WiFi connectivity options, providing flexibility in connecting the device to your laptop.

USB vs. WiFi Versions Comparison Table

Feature	USB Version	WiFi Version
Connection Method	USB Only	USB & WiFi
Compatibility	Windows 7 (32-bit) & 10	Windows 7 (32-bit) & 10
System Requirements	Supports Windows OS	Supports Windows OS
License & Firmware Updates	Via VX Manager	Via VX Manager
Full OBD2 Functionality	Yes	Yes
Multi-Service Functions	Yes	Yes
Advanced Diagnostics	Yes	Yes

Note: TECH2WIN only supports Windows 7 32-bit.

Supported Opel Vehicles:

Here’s the list of Opel vehicles supported by the V2019 VXDIAG VCX NANO GDS2 software:

Note: Tech2win software does not support Saab or Opel.

Adam
Ampera
Antara
Ampera-e
Astra-K
Cascada
Combo-D
Corsa-E
Crossland X
Grandland X
Insignia
Insignia-B
Karl / Viva
Meriva-B
Mokka
Movano-B
Vivaro-B
Zafira-B
Zafira-C
Astra-J
Antara

WiFi Version VXDIAG VCX NANO for GM OPEL 2

Diagnostic and Programming Capabilities

Full System Diagnostics: Enables comprehensive diagnostics for all vehicle systems, including engine, transmission, ABS, SRS, and more. The tool retrieves diagnostic trouble codes, performs live data streaming, and conducts active tests.
ECU Programming and Coding: Supports online programming and coding through the GM Service Programming System (SPS), allowing for ECU updates, reprogramming, and component adaptation.

Global Diagnostic System (GDS2) Features

GDS2 Capabilities:
- Read and clear codes, freeze frame data, and code status.
- Read VIN, ECU part numbers, and software numbers.
- Record, store, and replay stored data.
- Control and monitor output control functions.
- Configure and reset functions.
- Record or display the history of previous vehicle diagnostic sessions.
Tech-2-Win Functionality: Offers all features and functions of the GM Tech 2 tool, enabling diagnostics on older GM models. Note: Tech-2-Win must be installed on a Windows 7 32-bit system.
Service Programming System (SPS/SPS2 Techline Connect)
- Requirements: SPS programming requires a General Motors (GM) online account.
- Functionality: Supports pass-through programming for older GM models and Global A platform vehicles.
- Programming Speed Improvement: Reprogramming speed is 20%-70% faster than with the Tech 2. For example, reprogramming a Tahoe Hybrid with 7 ECUs typically takes 2 hours with the Tech 2, but with the VCX Nano, it only takes 45 minutes, representing a 64% improvement. This significant speed increase allows you to service 10 vehicles in an 8-hour day instead of just 4, greatly enhancing revenue potential.
Setup Instructions:
- To use VCX Nano with SPS2 Techline Connect or PSA Service Box for Opel, install the Passthru Driver, and select the device as VXDIAG.

Advanced System Diagnostics

All System Diagnostics: Provides a data link to electronic control systems for comprehensive vehicle diagnosis, including ABS, SRS, engine, transmission, brake system, emission system, and more.
Special Functions:
- EPB (Electronic Parking Brake System): Deactivates/activates the brake control system, assists with brake fluid control, and more.
- SAS (Steering Angle Sensor Calibration): Supports calibration of the steering angle sensor.
- TPMS (Tire Pressure Monitoring System): Allows TPMS programming and reset procedures.
- ABS (Anti-lock Braking System): Performs various bi-directional tests for ABS and SRS.
- ECU Information Reading: Retrieves detailed ECU information.
- DPF Regeneration: Supports various functions related to the Diesel Particulate Filter system.
- BMS (Battery Maintenance System): Re-matches the control module and sensor for accurate battery detection.
Multi-Service Functions:
- Oil Reset: Allows reset of the engine oil life system.
- Electronic Throttle Position Reset: Resets throttle actuators to default settings.
- Gearbox Matching: Completes gearbox self-learning to improve gear shifting quality.
- Sunroof Initialization: Configures sunroof functions.
Active Test: Sends and retrieves information from the vehicle control module for specific functions, saving diagnostic time.

OBD2 Full Functionality

Reading and Erasing Codes: Displays and clears Diagnostic Trouble Codes (DTCs), resets monitors.
Data Stream: Reads and displays live ECU/PCM data stream, plotting functions graphically, and stores freeze frame data.
I/M Readiness Status: Shows the operational status of emissions-related systems.
O2 Sensor Test: Retrieves O2 sensor monitor test results.
On-Board Monitor Test: Displays test results for emission-related components and systems.
Component Testing: Actuates certain vehicle components to test their operability.

WiFi Version VXDIAG VCX NANO for GM OPEL 3

How to Resolve "License Expired" Issues

Update VX Manager: Download and install the latest VX Manager.
Connect Device: Ensure the device is connected to your laptop with an active network connection.
Renew License: Open VX Manager, click "Firmware" to update, then select "Update license" to renew.

Lifetime License and Updates

Lifetime License: The VCX NANO includes a lifetime license with easy updates available through VX Manager.
Firmware Updatable: The device supports firmware updates, ensuring it stays current with the latest vehicle models and diagnostic protocols.

Regulatory Compliance

Safety and Reliability: Complies with CE and FCC standards.

Important Notice

The device supports GDS2/RDS3/TECH2WIN software, but we do not provide an online account.
If you use Techline software to do online work, do not install our offline version of the software on your computer.

Our offline version of the software cannot be installed, otherwise, Techline will not be able to use it.
If you have installed our offline version of the software, please uninstall it and only install Techline.

Newest Tech Support:

VXDIAG GDS2 T2W and Techline Connect Installation Tips for One PC

Summary Table of Key Features

Feature	Description
SAE-J2534 Compatibility	Fully compatible with SAE-J2534-1 and SAE-J2534-2 standards.
Protocol Support	Supports CAN, UART, KW2000, Class2, GM LAN.
Software Compatibility	Works with GM Tech-2-Win, GDS2, SPS2. Supports GDS2 V2024.05.08.
Connectivity	Offers both USB and WiFi connectivity options.
Full System Diagnostics	Diagnostics for engine, transmission, ABS, SRS, and more.
ECU Programming	Online programming via GM SPS.
GDS2 Capabilities	Read/clear codes, freeze frame data, VIN, ECU info, and more.
Tech-2-Win Functionality	All features of the GM Tech 2 tool.
Special Functions	EPB, SAS Calibration, TPMS, ABS, ECU, DPF Regeneration, BMS, etc.
Active Test	Sends and retrieves control module information for specific functions.
OBD2 Functions	Reading/erasing codes, data stream, I/M readiness, O2 sensor test, etc.
Lifetime License and Updates	Includes a lifetime license with firmware updates.

Software Installation and Connection Steps:

If you want to learn about the following:

Package Contents

1pc x VXDiag VCX NANO OBD2 Scanner for GM
1pc x USB cable

Still have questions?

Want to learn more about the VCX NANO?
Want to hear more reviews from other buyers?
Contact us via online chat!

Tech Support

I. Installation and Setup

II. Diagnostic and Programming Cases

III. License Issues

IV. Software Use and Troubleshooting

V. Vehicle Support and List

VXDIAG VCX GM Scanners: Holden Car List for GDS2 and Tech2Win

FAQs

FAQs - VCX Nano for GM WIFI Version

Enter keywords for answers:

1. Question: I need to clear codes on my 2014 Chevy Volt. I just bought the VXDIAG VCX NANO for GM/OPEL. I have a laptop with Windows 10 Home. Will this work? Do I need anything else to clear the codes?

Hi, you’re good to go with the GDS2 software for your 2014 Chevy Volt. However, you’ll need to upgrade your laptop to Windows 10 Pro, as the Home version isn’t supported. If you have any other questions, feel free to ask!

2. Question: Can this be used to reprogram the speed limit governor (limiter) on a 2019 Chevy Bolt EV?

Answer: Hi, to adjust the speed limiter on your 2019 Chevy Bolt EV, you’ll need to do it through an official online subscription. Let us know if you have any other questions!

3. Question: Does this work with Windows 11 Pro? Can it program a vehicle VIN to the TCM for a 2011 GMC Yukon? Can it program custom idle speed?

Answer: We haven’t tested it on Windows 11 Pro, so we recommend using Windows 10 Pro 64-bit. For programming the VIN or custom idle speed, you would need an official online subscription to use with our device as a J2534 interface. Hope this helps!

4. Question: Can I use this to program the BCM module for a 2003 Oldsmobile Alero?

Answer: You can definitely use it for BCM programming, but you’ll need an ACDelco online subscription to get it done.

5. Question: Hi, has Tech2Win been tested on a Hyper-V virtual machine running Windows?

Answer: We haven't tested Tech2Win on a Hyper-V virtual machine, as it’s only supported on Windows 10 Pro and Windows 7 Pro 32-bit.

6. Question: Is this product compatible with a 2006-2007 Opel Signum for diagnosis and programming?

Answer: Unfortunately, the device and GDS2 software only support Opel models from 2010 onward. Tech2Win cannot support older Opel models before 2010.

7. Question: I have a 2009 Chevy HHR, and I need to reset the fuel composition. Can this tool do that? My alcohol fuel percentage reading is incorrect.

Answer: To perform a fuel composition reset on your 2009 Chevy HHR, you'll need to use the tool with an online SPS2 Techline Connect subscription.

8. Question: Is Windows 10 Professional compatible with the Nano GM wireless/wired device?

Answer: Hello, you can use GDS2 software on Windows 10 Pro 64-bit, and Tech2Win also runs on that system. However, factory engineers advise using Windows 7 Pro 32-bit for Tech2Win, as it offers better stability.

9. Question: Hi, is this compatible with Holden vehicles? Specifically a 2009 Holden VE Commodore.

Answer: Apologies, but for your vehicle, Tech2Win software is required. However, our version of Tech2Win does not support Holden vehicles.

10. Question: Is it possible to disable AFM on a 2009 GMC Sierra truck?

Answer: Hi, we checked with our engineers, and they confirmed that to disable AFM, you'll need to use the original online SPS2 service.

11. Question: I have an N52GM08931 VCX Nano with a GM GDS2 license. Is it possible to add Ford/Mazda software to it?

Answer: Hi, the VCX Nano GM is designed to support only one brand, so adding a Ford license isn't possible. However, we do have a new FD series that supports both GM and Ford. Thank you for your understanding.

12. Question: Will this allow me to clear codes on a 2015 Chevy Volt?

Answer: Yes, it supports the 2015 Chevy Volt and can clear codes using the GDS2 software directly.

13. Question: My USB mini port is broken, but I have the WiFi version of GDS2. How do I get the WiFi to work?

Answer: For WiFi setup, it's simple. Just connect the VCI to the car to power it up. On your computer, open the network connections, and you'll find a WiFi network named "VCX VCI*****". Click to connect, and use the password "12345678". These are the steps from our official website: https://vxdiag.com/pages/how-to-connect-devices
